Low Voltage MOSFET
KUS220N10C
DISCONTINUED
Split Gate Trench MOSFETs, PDFN56, 100V, 30A
Application
· Consumer - Battery Charger Adaptor
· Consumer - LCD/OLED TV SMPS
· Industrial - Server Power
Features
· Fast switching time
· Low on resistance and gate charge
· Suitable for using DC/DC Converter, Synchronous Rectification and a load switch
| Item No | KUS220N10C |
|---|---|
| Status | Discontinued |
| AEC-Q | N |
| Package | PDFN56 |
| Polarity | N |
| BVDSS[V] | 100 |
| ID[A] | 30 |
| PD[W] | 36.7 |
| RDS(ON)@10V[Ω] | 0.022 |
| Qg [nC] | 17 |
| Vth_MIN[V] | 2 |
| Vth_MAX[V] | 4 |
| Ciss[pF] | 1060 |
| ESD DIODE | N |
Product Datasheet
-
[Product Datasheet] KUS220N10C.pdf
554.7 KBPDF
-
[Marking Information] M KUS220N10C.pdf
54.2 KBPDF
-
[Package Dimension] PDFN56 PKG.pdf
57.7 KBPDF
-
[Packing Information] PDFN56 Packing.pdf
396.7 KBPDF
-
[Recommended Pad Dimension] PDFN56 RPD.pdf
50.3 KBPDF
