Low Voltage MOSFET
KUS140N10C
Split Gate Trench MOSFETs, PDFN56, 100V, 44A
Application
· Consumer - LCD/OLED TV SMPS
Features
· Fast switching time
· Low on resistance and gate charge
· Suitable for using DC/DC Converter, Synchronous Rectification and a load switch
| Item No | KUS140N10C |
|---|---|
| Package | PDFN56 |
| Polarity | N |
| BVDSS[V] | 100 |
| ID[A] | 44 |
| PD[W] | 49 |
| RDS(ON)@10V[Ω] | 0.014 |
| Qg [nC] | 26 |
| Vth_MIN[V] | 2 |
| Vth_MAX[V] | 4 |
| Ciss[pF] | 1700 |
| ESD DIODE | N |
Product Datasheet
-
[Product Datasheet] KUS140N10C.pdf
881.7 KBPDF
-
[Marking Information] M KUS140N10C.pdf
104.5 KBPDF
-
[Package Dimension] PDFN56 PKG.pdf
57.7 KBPDF
-
[Packing Information] PDFN56 Packing.pdf
396.7 KBPDF
-
[Recommended Pad Dimension] PDFN56 RPD.pdf
50.3 KBPDF
Ordering Information
| Part Number | Status | Compliance | Package | Packing Type | Packing Q’ty[pcs] | RoHS | REACH | Samples | ||
|---|---|---|---|---|---|---|---|---|---|---|
| AEC-Q | Pb-Free | Halogen Free | ||||||||
| KUS140N10C | - | - | - | - | - | - | - | - | - | Request Sample |
* EU RoHS Exemption Usage
A few of KEC products are RoHS-compliant with the use of an EU RoHS exemption for lead, specifically.
For the latest information regarding applicable RoHS exemptions and their expiration dates, please contact the Quality Team.
A few of KEC products are RoHS-compliant with the use of an EU RoHS exemption for lead, specifically.
For the latest information regarding applicable RoHS exemptions and their expiration dates, please contact the Quality Team.
