General Purpose Bipolar Transistors
KTA1504UL
NEW
General Purpose Transistor, SOT-23, -50V, -0.15A
Application
· Switching
· General Purpose
Features
· Excellent hFE Linearity : hFE(0.1mA)/hFE(2mA)=0.95(typ.)
· Low Noise : NF=1dB(typ.), 10dB(max.)
| Item No | KTA1504UL |
|---|---|
| Status | NEW |
| AEC-Q | N |
| Package | ULP-3(1) |
| Polarity | PNP |
| VCEO[V] | -50 |
| IC[A] | -0.15 |
| PC[W] | 0.15 |
| hFE_Min | 70 |
| hFE_Max | 400 |
| VCE(SAT)_MAX[V] | -0.3 |
Product Datasheet
-
[Product Datasheet] KTA1504UL_R1.pdf
1.1 MBPDF
-
[Marking Information] M KTA1504UL_R0.pdf
673.7 KBPDF
-
[Package Dimension] ULP-3(1) PKG.pdf
622.2 KBPDF
-
[Packing Information] ULP-3(1) Packing.pdf
3.2 MBPDF
-
[Recommended Pad Dimension] ULP-3(1) RPD.pdf
608.4 KBPDF
