Low Voltage MOSFET
KU080P03C
Application
· battery powered applications
· load switch
Features
· Fast switching time
· Low on resistance and gate charge
| Item No | KU080P03C |
|---|---|
| Package | PDFN56 |
| Polarity | P |
| BVDSS[V] | -30 |
| ID[A] | -70 |
| PD[W] | 80 |
| RDS(ON)@10V[Ω] | 0.008 |
| RDS(ON)@4.5V[Ω] | 0.01 |
| Qg [nC] | 42 |
| Vth_MIN[V] | -1 |
| Vth_MAX[V] | -2 |
| Ciss[pF] | 4810 |
| ESD DIODE | N |
Product Datasheet
-
[Product Datasheet] KU080P03C.pdf
696.3 KBPDF
-
[Marking Information] M KU080P03C.pdf
162.8 KBPDF
-
[Package Dimension] PDFN56 PKG.pdf
57.7 KBPDF
-
[Packing Information] PDFN56 Packing.pdf
396.7 KBPDF
-
[Recommended Pad Dimension] PDFN56 RPD.pdf
50.3 KBPDF
Ordering Information
| Part Number | Status | Compliance | Package | Packing Type | Packing Q’ty[pcs] | RoHS | REACH | Samples | ||
|---|---|---|---|---|---|---|---|---|---|---|
| AEC-Q | Pb-Free | Halogen Free | ||||||||
| KU080P03C-EL/H | Active | No | Yes | Yes | PDFN56 | Taping | 3,000 | Yes | Yes | Request Sample |
* EU RoHS Exemption Usage
A few of KEC products are RoHS-compliant with the use of an EU RoHS exemption for lead, specifically.
For the latest information regarding applicable RoHS exemptions and their expiration dates, please contact the Quality Team.
A few of KEC products are RoHS-compliant with the use of an EU RoHS exemption for lead, specifically.
For the latest information regarding applicable RoHS exemptions and their expiration dates, please contact the Quality Team.
